FEATURES
- 6 digit stepper motor counter
- CT ratio programmable through DIP switch
- True RMS measurement
- Reverse indication for wrong wiring polarity
- Direct Reading, no multiplication Factor
PARAMETERS
| >> kWh |
SPECIFICATION
| Display | : | 1 row of 6 digits (electromechanical) | ….. |
| Display Scrolling | : | Automatic/ Manual | ….. |
| Display Reset. | : | Energy | ….. |
| Electrical Connection | : | 3Φ- 4 wire/ 1Φ- 2 wire | ….. |
| Input Voltage Range | : | 0-500 VAC (L-L) | ….. |
| Input Current Range | : | 0.015 A – 6 AAC/ Direct 60 A optional | ….. |
| Frequency | : | 45 Hz to 65 Hz | ….. |
| C.T. primary | : | Programmable | |
| C.T. Secondary | : | Programmable |
ADVANTAGES
- To caution on the Extra Energy Consumption
- Energy Management system
- CT Ratio Site programmable reduces inventory
APPLICATION
| » Control Panel | » Test Bench | ….. |
| » Distribution Systems | » Process Control & SCADA | ….. |
| » Generator Sets | » Energy Management | ….. |
| » Motor Control |
